Contactor Application:
Power Contactor
Coil Voltage:
120 V
Pole and Throw Configuration:
3
Width:
45 mm
Contact Current:
12A
Control Circuit Voltage Uc:
120 V
Function:
Multifunction
Operational Current Ie:
12A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
85mm
Standards/Approvals:
IEC 61508-2, IEC61508, IP20, ISO 13849-1, PRS, RCM, RMRS, UKCA, UL, ABS, CCC, CE, CSA, DNV, EAC, IEC 60529, IEC 60947-4-1
Number of Auxiliary Contacts:
4
Auxiliary Contact Configuration:
2 NO/2 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
141mm
Normal State Configuration:
NO/NC
Contact Voltage:
690V
Power Rating:
5.5kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
