Contactor Application:
Power Contactor
Coil Voltage:
120 V
Pole and Throw Configuration:
3
Width:
45 mm
Contact Current:
22A
Control Circuit Voltage Uc:
120 V
Function:
Multifunction
Operational Current Ie:
22A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
58mm
Standards/Approvals:
CCC, CE, CSA, DNV, EAC, IEC 60529, IEC 60947-4-1, IEC61508, IEC 61508-2, IP20, ISO 13849-1, PRS, RCM, RMRS, UKCA, UL
Number of Auxiliary Contacts:
1
Auxiliary Contact Configuration:
1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
73mm
Normal State Configuration:
1 NC
Contact Voltage:
690V
Power Rating:
5.5kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
