Contactor Application:
AC-3, Power Contactor
Coil Voltage:
240 V
Pole and Throw Configuration:
4
Width:
45 mm
Contact Current:
9A
Control Circuit Voltage Uc:
240 V
Function:
Mirror Contact
Operational Current Ie:
9A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
57.5mm
Standards/Approvals:
CE, ABS, CCC, CSA, DNV, EAC, IEC 60529, IEC 60947-4-1, IEC61508, IEC 61508-2, IP20, PRS, RCM, RMRS, UKCA, UL
Mount Type:
DIN Rail
Series:
3RT25
Depth:
73mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
690V
Power Rating:
4kW
Number of Poles:
4
Minimum Operating Temperature:
-25°C
