Contactor Application:
Control
Coil Voltage:
42 V ac
Pole and Throw Configuration:
3
Width:
90 mm
Contact Current:
9A
Control Circuit Voltage Uc:
42 V ac
Function:
AC
Operational Current Ie:
9A
Product Type:
Reversing Contactor
Maximum Operating Temperature:
50°C
Terminal Type:
Screw Clamp
Minimum Operating Temperature:
-25°C
Length:
58mm
Standards/Approvals:
UL 94, UL 60947-4-1, UL 60335-2-40:Annex JJ, IEC 60947-5-1, IEC 60947-4-1, IEC 60947-1 Annex Q, IEC 60947, IEC 60695-2-1, IEC 60529, IEC 60335-2-40:Annex JJ, IEC 60335-1:Clause 30.2, IEC 60068-2-30, EN/ISO 13849-1, EN 60947-5-1, EN 60947-4-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 14
Number of Auxiliary Contacts:
1
Auxiliary Contact Configuration:
1 NC
Mount Type:
Plate
Series:
LC2K
Depth:
57mm
Normal State Configuration:
3 NO
Contact Voltage:
690V ac
Power Rating:
4kW
Number of Poles:
3
