Contactor Application:
AC-3, Power Contactor
Coil Voltage:
110 V dc
Pole and Throw Configuration:
3PST
Width:
61 mm
Contact Current:
40A
Control Circuit Voltage Uc:
110 V
Function:
Mirror Contact, Safety
Operational Current Ie:
40A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Spring Loaded
Length:
102mm
Standards/Approvals:
CCC, CE, CSA, DNV, EMV, IEC 60947-4-1, IEC 60947-5-1, IEC 61508, RMRS, RoHS, UKCA, UL A600, UL Q600, EPD, IEC 60068-2-30, IEC 60529, IEC 60947-1
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT25
Depth:
107mm
Normal State Configuration:
2 NO/2 NC
Contact Voltage:
690V
Power Rating:
11kW
Number of Poles:
4
Minimum Operating Temperature:
-25°C
