Contactor Application:
Power
Coil Voltage:
175/280 V
Pole and Throw Configuration:
3P
Width:
55 mm
Contact Current:
80A
Control Circuit Voltage Uc:
280 V
Operational Current Ie:
80A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Normal State Configuration:
1 NC
Length:
114mm
Standards/Approvals:
IEC 62061, IEC 60068-2-30, IEC 60204-1, IEC 60947-5-1, IEC 60947-4-1, IEC 60947-1, ISO 13849-1, EN ISO 13849-1, EN 62061, IEC 61508, EN 60715
Number of Auxiliary Contacts:
1
Contact Voltage:
690V
Mount Type:
Screw and Snap-On
Series:
3RT2
Depth:
130mm
Minimum Operating Temperature:
-25°C
Auxiliary Contact Configuration:
1 NC
Power Rating:
37kW
Number of Poles:
3
