Contactor Application:
AC-3, Power Contactor
Coil Voltage:
48 V dc
Pole and Throw Configuration:
4
Width:
61 mm
Contact Current:
25A
Control Circuit Voltage Uc:
48 V
Function:
Mirror Contact
Operational Current Ie:
25A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
85mm
Standards/Approvals:
IP20, ABS, CE, ISO 13849-1, RCM, RMRS, UKCA, UL, CCC, CSA, DNV, EAC, IEC 60529, IEC 60947-4-1, IEC61508, IEC 61508-2
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT25
Depth:
107mm
Normal State Configuration:
2 NC/2 NO
Contact Voltage:
400V
Power Rating:
11kW
Number of Poles:
4
Minimum Operating Temperature:
-25°C
