Contactor Application:
AC-3
Coil Voltage:
600 V
Pole and Throw Configuration:
3P
Width:
45 mm
Contact Current:
9A
Control Circuit Voltage Uc:
600 V
Function:
Mirror Contact, Pipe S-Type, Safety
Operational Current Ie:
9A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Length:
85mm
Standards/Approvals:
PRS, IP20, ISO 13849-1, RCM, RMRS, UKCA, UL, ABS, CCC, CE, CSA, DNV, EAC, IEC 60529, IEC 60947-4-1, IEC61508, IEC 61508-2
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT
Depth:
97mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
7.5kW
Number of Poles:
3
Minimum Operating Temperature:
-25°C
