Contactor Application:
AC-3, AC-3e, Traction Contactor
Coil Voltage:
72 V dc
Pole and Throw Configuration:
3P
Width:
45 mm
Contact Current:
22A
Control Circuit Voltage Uc:
72 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
12A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Terminal Type:
Spring Loaded
Length:
70mm
Standards/Approvals:
ABS, CCC, CE, DNV, EAC, EMV, IEC 60947, IEC 61508, ISO 13849, KC, PRS, RCM, RMRS, UKCA, UL, UL (A600/Q600)
Number of Auxiliary Contacts:
1
Auxiliary Contact Configuration:
1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
121mm
Normal State Configuration:
1 NC
Contact Voltage:
690V
Power Rating:
5.5kW
Number of Poles:
3
Minimum Operating Temperature:
-40°C
