Contactor Application:
AC-3, AC-3e, Traction Contactor
Coil Voltage:
72 V dc
Pole and Throw Configuration:
3P
Width:
70 mm
Contact Current:
80A
Control Circuit Voltage Uc:
72 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
80A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Normal State Configuration:
1 NO/1 NC
Length:
140mm
Standards/Approvals:
RMRS, ISO 13849, RCM, UKCA, UL, UL/CSA, CCC, CE, CSA, EAC, IEC 60068, IEC 60077, IEC 60947, IEC 61508
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
152mm
Minimum Operating Temperature:
-40°C
Contact Voltage:
1kV
Power Rating:
37kW
Number of Poles:
3
