Contactor Application:
Traction Contactor, AC-3e, AC-3
Coil Voltage:
72 V dc
Pole and Throw Configuration:
3P
Width:
55 mm
Contact Current:
90A
Control Circuit Voltage Uc:
72 V dc
Function:
Pipe S-Type, Mirror Contact
Operational Current Ie:
80A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Length:
114mm
Standards/Approvals:
UL, UKCA, RMRS, RCM, ISO 13849-1, IP20, IEC 61508-2, IEC61508, IEC 60947-4-1, IEC 60529, EAC, DNV, CSA, CE, CCC
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
130mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
45kW
Number of Poles:
3
Minimum Operating Temperature:
-40°C
