Contactor Application:
Traction Contactor, AC-3e, AC-3
Coil Voltage:
110 V dc
Pole and Throw Configuration:
3P
Width:
70 mm
Contact Current:
125A
Control Circuit Voltage Uc:
110 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
80A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Normal State Configuration:
1 NO/1 NC
Length:
140mm
Standards/Approvals:
ISO 13849-1, RCM, RMRS, UKCA, UL, IEC 60947-4-1, IEC61508, IEC 60529, IEC 61508-2, EAC, DNV, IP20, CSA, CE, CCC
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
152mm
Minimum Operating Temperature:
-40°C
Contact Voltage:
1kV
Power Rating:
37kW
Number of Poles:
3
