Contactor Application:
AC-3, AC-3e, Traction Contactor
Coil Voltage:
24 V dc
Pole and Throw Configuration:
3P
Width:
55 mm
Contact Current:
80A
Control Circuit Voltage Uc:
24 V
Function:
Mirror Contact, Pipe S-Type
Operational Current Ie:
65A
Product Type:
Contactor
Maximum Operating Temperature:
70°C
Length:
114mm
Standards/Approvals:
UKCA, RCM, UL, ABS, CCC, CE, CSA, DNV, EAC, IEC 60947-4-1, IEC 60947-5-1, IEC 61508, PRS
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT2
Depth:
130mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
30kW
Number of Poles:
3
Minimum Operating Temperature:
-40°C
