Contactor Application:
Contactor
Coil Voltage:
220/240 V ac
Pole and Throw Configuration:
3P
Width:
70 mm
Contact Current:
140A
Control Circuit Voltage Uc:
240 V
Function:
Mirror Contact, Pipe S-Type, Safety
Operational Current Ie:
140A
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Minimum Operating Temperature:
-25°C
Length:
140mm
Standards/Approvals:
DNV, EAC, IEC 60529, IEC 60947-4-1, IEC61508, IP20, RCM, UKCA, UL, CCC, CE, CSA
Number of Auxiliary Contacts:
2
Auxiliary Contact Configuration:
1 NO/1 NC
Mount Type:
DIN Rail
Series:
3RT24
Depth:
152mm
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
690V
Power Rating:
96kW
Number of Poles:
3
