Pole and Throw Configuration:
3
Width:
75 mm
Supply Voltage:
690 V
Reset Method:
Push Button
Adjustable Current Range:
23 to 32 A
FLC Motor Rating:
23 to 32 A
Product Type:
Thermal Overload Relay
Maximum Operating Temperature:
60°C
Terminal Type:
Screw Clamp
Depth:
121mm
IP Rating:
IP20
Length:
123mm
Standards/Approvals:
EN/IEC 60947-5-1, EN/IEC 60947-4-1, EN 50495, CSA C22.2 No 60947-4-1, UL 60947-5-1, UL 60947-4-1, CSA C22.2 No 60947-5-1, GB/T 14048.5, GB/T 14048.4
Number of Auxiliary Contacts:
2
Mount Type:
DIN Rail
Better World Product:
Yes
Series:
LRD
Relay Contact Current:
32 A
Normal State Configuration:
1 NO/1 NC
Contact Voltage:
1kV ac
Power Rating:
22kW
Minimum Operating Temperature:
-20°C
title:
LRD332
Series:
TeSys
Accessory Type:
Thermal Overload Relay
Packaging:
Box
For Use With/Related Products:
LC1D40A, LC1D50A and LC1D65A Series
standardLeadTime:
5 Weeks
Manufacturer:
Schneider Electric
