Pole and Throw Configuration:
3
Width:
45 mm
Reset Method:
Automatic & Manual
Adjustable Current Range:
0.1 to 0.4 A
FLC Motor Rating:
0.1 to 0.4 A
Product Type:
Overload Relay
Maximum Operating Temperature:
60°C
Terminal Type:
Screw
Depth:
83.5mm
Normal State Configuration:
1 NO/1 NC
IP Rating:
IP20
Length:
69.7mm
Standards/Approvals:
CCC approved, UL Approved, IEC 81346-2, IEC 65029, IEC 61508, IEC 61000-4-6, IEC 61000-4-5, IEC 61000-4-4, IEC 61000-4-3, IEC 61000-4-2, IEC 60068-2-27, EAC Approved, CSA Approved, CE Approved
Number of Auxiliary Contacts:
2
Mount Type:
Direct
Series:
3RB
Relay Contact Current:
400 mA
Minimum Operating Temperature:
-25°C
Contact Voltage:
690V ac
Power Rating:
90W
