Contactor Application:
Control Circuit
Coil Voltage:
24 V
Pole and Throw Configuration:
5
Width:
45 mm
Contact Current:
10A
Control Circuit Voltage Uc:
24 V
Function:
Reversing
Product Type:
Contactor
Maximum Operating Temperature:
60°C
Terminal Type:
Screw Clamp
Minimum Operating Temperature:
-5°C
Length:
77mm
Standards/Approvals:
UL 60947-5-1, UKCA, RoHS, REACH, JIS C8201-5-1, GB/T 14048.5, EN/IEC 60947-5-1, EAC, CSA C22.2 No 60947-5-1, CSA, CE, CCC, CB scheme, UL
Number of Auxiliary Contacts:
5
Auxiliary Contact Configuration:
3 NO/2 NC
Mount Type:
DIN Rail
Better World Product:
Yes
Series:
CAD
Depth:
93mm
Normal State Configuration:
3 NO/2 NC
Contact Voltage:
690V
Number of Poles:
5
