Body Orientation:
Horizontal
Mounting Type:
Surface Mount
Actual Diameter:
0.098" (2.50mm ID), 0.256" (6.50mm OD)
HTSUS:
8536.69.4040
RoHS Status:
ROHS3 Compliant
Mounting Feature:
-
Thread Size:
-
Operating Temperature:
-25°C ~ 85°C
Industry Recognized Mating Diameter:
2.50mm ID (0.098"), 5.50mm OD (0.217")
Internal Switch(s):
Single Switch, Normally Closed
Shielding:
Unshielded
Voltage - Rated:
24VDC
REACH Status:
REACH Unaffected
Includes:
-
edacadModel:
PJ-002BH-SMT-TR Models
Number of Positions/Contacts:
2 Conductors, 3 Contacts
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/404626
Manufacturer:
CUI Devices
Insulation Color:
-
Gender:
Male
Connector Type:
Jack
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Body Material:
-
Termination:
Solder
standardLeadTime:
20 Weeks
Current Rating (Amps):
5 A
Housing Material:
Polyamide (PA6T), Nylon 6T
Body Color:
Black
Ingress Protection:
-
Features:
Board Guide, Solder Retention
Mounting Type:
Surface Mount, Right Angle
Mating Length/Depth:
0.350" (8.90mm)
Series:
-
Packaging:
Tape & Reel (TR)
Contact Material - Plating:
Silver
Contact Material:
Brass, Copper Alloy
Base Product Number:
PJ-002
ECCN:
EAR99
