Actual Diameter:
0.102" (2.60mm)
HTSUS:
8536.69.4030
RoHS Status:
ROHS3 Compliant
Thread Size:
M6x0.5
Operating Temperature:
-20°C ~ 70°C
Panel Hole Size:
0.244" (6.20mm)
Industry Recognized Mating Diameter:
2.50mm (0.094", 3/32", Sub Mini, Miniature) - Headphone
Internal Switch(s):
Does Not Contain Switch
Shielding:
Unshielded
Voltage - Rated:
30VAC/DC
Cable Opening:
-
Insulation Color:
-
REACH Status:
REACH Unaffected
Includes:
2 pcs - 1 Connector, 1 Nut
Signal Lines:
Stereo (3 Conductor, TRS)
Number of Positions/Contacts:
3 Conductors, 3 Contacts
Package:
Bulk
Gender:
Female
Connector Type:
Phone Jack
Moisture Sensitivity Level (MSL):
Not Applicable
Body Material:
Brass
Termination:
Solder Eyelet(s)
standardLeadTime:
28 Weeks
Current Rating (Amps):
500 mA
Housing Material:
-
Body Color:
Silver, White
Features:
Mounting Hardware, Thread Lock
Mounting Type:
Panel Mount, Through Hole
Mating Length/Depth:
0.433" (11.00mm)
Series:
4831
Contact Material - Plating:
Gold
Contact Material:
Brass
ECCN:
EAR99
This is manufactured by Schurter Inc.. The manufacturer part number is 4831.2300. Its actual diameter is 0.102" (2.60mm). It is assigned with possible HTSUS value of 8536.69.4030. The product is rohs3 compliant. It has a typical thread size of m6x0.5. The product has -20°c ~ 70°c operating temperature range. The product features a panel hole size of 0.244" (6.20mm). The product has 2.50mm (0.094", 3/32", sub mini, miniature) - headphone industrial recognised mating diameter. Internal switch options: does not contain switch. Furthermore, the product is shielded with unshielded. It also exhibits voltage rating of 30vac/dc. In addition, it is reach unaffected. The product is also supplied with 2 pcs - 1 connector, 1 nut. Features stereo (3 conductor, trs) signal lines. The product consists of 3 conductors, 3 contacts positions or contacts. It is shipped in bulk package . In addition, female is the available "Gender" of the product. phone jack Connector type offer robust functionality. Its typical moisture sensitivity level is not applicable. The product's body is nicely designed from brass materials. The product features solder eyelet(s) termination style. It has a long 28 weeks standard lead time. Additionally, the product's output is 500 ma. The body has a classic silver, white colour. The splendid features of the product include mounting hardware, thread lock. The product is available in panel mount, through hole configuration. The product has 0.433" (11.00mm) mating length or depth. The product 4831, is a highly preferred choice for users. While the contact is gold. The product is made from sturdy brass materials. The product is designated with the ear99 code number.
