Maximum Temperature:
+40°C
Minimum Temperature:
0°C
Application:
Access Devices, Network Hubs, Peripherals, Portable Equipment
Protection Features:
Over Current Protection, Over Voltage Protection, Short Circuit Protection
Output Current Range:
0 → 0.75A
Maximum Input Current:
600mA
Standards Met:
CE, CULus, EN 50082-1, EN 55022 Class B/CISPR22 Class B, EN 55024, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, FCC Class B, UL
Input Connector:
IEC C14
Input Frequency Range:
47 → 63Hz
Energy Efficiency Level:
VI
Overall Length:
103mm
Overall Depth:
33.5mm
Number of Outputs:
1
Operating Temperature Range:
0 → +40 °C
Rated Output Power:
18W
Ripple And Noise:
240mV Pk-Pk
Output Voltage Rating:
24 V dc
Special Features:
Class B EMI, Low Cost, Low Profile Design, Non-Vented, Spill-Proof Case
Power Signal Conversion Type:
AC-DC
Overall Dimensions:
103 x 49 x 33.5mm
Mounting Type:
Desktop
Weight:
140g
Line Regulation Range:
±5%
Series:
PSAA18U
Input Voltage Range:
90 → 264 V ac
Cable Length:
1500mm
Output Connection Type:
DC Plug
Load Regulation Range:
±5%
Overall Width:
49mm
