Dimensions:
2.3 x 1.3 x 0.15mm
Maximum Continuous Drain Current:
10 A
Transistor Material:
Si
Width:
1.3mm
Transistor Configuration:
Common Drain
Maximum Drain Source Voltage:
20 V
Package Type:
WLCSP
Number of Elements per Chip:
2
Minimum Gate Threshold Voltage:
0.4V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
17 nC @ 4.5 V
Channel Type:
N
Typical Input Capacitance @ Vds:
1545 pF @ 10 V
Length:
2.3mm
Pin Count:
6
Typical Turn-Off Delay Time:
34 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
2 W
Series:
PowerTrench
Maximum Gate Source Voltage:
±12 V
Height:
0.15mm
Typical Turn-On Delay Time:
12 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
20 mΩ
