Maximum Temperature:
+60°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-20°C
AC or DC Input Voltage:
Ac
Width:
276mm
MTBF:
122.5Kh
Maximum Output Voltage:
48V dc
Electrical Phase:
3
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
14 (400 V ac) ms, 30 (500 V ac) ms
Standards Met:
Compliance to EN 55011 (CISPR11), Compliance to EN 61000-4-2, EN 55022 (CISPR22), EN 60950-1 Approved, EN 61000-6-2 (EN 50082-2) Heavy Industry Level Criteria A, EN 61204-3, EN 61204-3 Class B, ENV 50204, UL 508, UL 60950-1, 3 ,4, 5, 6, 8, 11
Maximum Input Current:
2A
Input Frequency Range:
47 → 63Hz
Efficiency:
92%
Input Voltage:
340 → 550V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
48 → 55V
Line Regulation:
±0.5%
Ripple And Noise:
80mV Pk-Pk
Range:
PST
Minimum Output Voltage:
48V dc
Allowed Circuit Configurations:
Parallel
Special Features:
Cooling by Free Air Convection, Optional Parallel Function(1+1), 100% Full Load Burn-In Test
Input Electrical Phase:
Three Phase
Power Signal Conversion Type:
AC-DC
Mounting Type:
DIN Rail
Output Current:
20 A
Application:
Industrial
Series:
PST-960
Depth:
100mm
Height:
125.2mm
Weight:
3.3kg
Output Voltage:
48 V dc
Power Rating:
960W
Maximum Input Voltage:
550V ac
Minimum Input Voltage:
340V ac
