Dimensions:
1.5 x 1 x 0.31mm
Maximum Continuous Drain Current:
9.5 A
Transistor Material:
Si
Width:
1mm
Transistor Configuration:
Single
Maximum Drain Source Voltage:
25 V
Package Type:
MICRO FOOT
Number of Elements per Chip:
1
Minimum Gate Threshold Voltage:
0.4V
Maximum Operating Temperature:
+150 °C
Typical Gate Charge @ Vgs:
22 nC @ 10 V
Channel Type:
N
Typical Input Capacitance @ Vds:
1315 pF@ 12.5 V
Length:
1.5mm
Pin Count:
6
Typical Turn-Off Delay Time:
25 ns
Mounting Type:
Surface Mount
Channel Mode:
Enhancement
Maximum Power Dissipation:
2.9 W
Maximum Gate Source Voltage:
±20 V
Height:
0.31mm
Typical Turn-On Delay Time:
15 ns
Minimum Operating Temperature:
-55 °C
Maximum Drain Source Resistance:
12.4 mΩ
