Maximum Temperature:
60°C
AC or DC Output Voltage:
Dc
Minimum Temperature:
-10°C
AC or DC Input Voltage:
Ac
Width:
65.5mm
MTBF:
136.8Kh
Maximum Output Voltage:
12V dc
Electrical Phase:
1
Protection Features:
Over Temperature Protection, Over Voltage Protection, Overload Protection, Short Circuit Protection
Type:
Switch Mode
Holdup Time:
32 (115 V ac) ms, 36 (230 V ac) ms
Standards Met:
-3, Compliance to EN 55011, Compliance to EN 61000-3-2, Compliance to EN 61000-4-2, EN 50082-2, EN 55022 (CISPR22) Class B, EN 55024, EN 60950-1 Approved, EN 61000-6-2, ENV 50204, UL 508, UL 60950-1, 3 ,4, 5, 6, 8, 11
Maximum Input Current:
2.6A
Input Frequency Range:
47 → 63Hz
Efficiency:
80%
Input Voltage:
85 → 264V ac
Number of Outputs:
1
Output Voltage Adjustment Range:
12 → 14V
Line Regulation:
±0.5%
Ripple And Noise:
80mV Pk-Pk
Range:
PS
Minimum Output Voltage:
12V dc
Special Features:
Cooling by Free Air Convection, LED Indicator
Input Electrical Phase:
Single Phase
Power Signal Conversion Type:
AC/DC-DC
Mounting Type:
DIN Rail
Output Current:
10 A
Application:
Industrial
Series:
PS-120
Depth:
100mm
Height:
125mm
Weight:
0.79kg
Output Voltage:
12 V dc
Power Rating:
120W
Maximum Input Voltage:
264V ac
Minimum Input Voltage:
88V ac
This is PS 120W Switch Mode DIN Rail Power Supply 12V dc/ 10A manufactured by Altech. The manufacturer part number is PS-12012. The product has 60°c maximum temperature. It has a/an dc output voltage . While its minimum temperature is -10°c. It has ac input voltage. Furthermore, the product is 65.5mm wide. The MTBF values include 136.8kh. Its output voltage (maximum) includes 12v dc. Its electrical phase configuration includes 1. It provides robust protection features, such as over temperature protection, over voltage protection, overload protection, short circuit protection. It comes in switch mode configuration. Additionally, its holdup time is about 32 (115 v ac) ms, 36 (230 v ac) ms . The product complies with all safety standards, such as -3, compliance to en 55011, compliance to en 61000-3-2, compliance to en 61000-4-2, en 50082-2, en 55022 (cispr22) class b, en 55024, en 60950-1 approved, en 61000-6-2, env 50204, ul 508, ul 60950-1, 3 ,4, 5, 6, 8, 11. While its maximum input current includes 2.6a. It has 47 → 63hz input frequency range . It is a highly efficient product with an 80% of high efficiency. Its input voltage is 85 → 264v ac. Additionally, the product is supplied with 1 outputs. It has 12 → 14v of output voltage adjustment range. Has a line regulation of ±0.5%. Carries 80mv pk-pk ripple and noise. It features ps range. The product features 12v dc minimum output voltage. The product also provides special features, such as cooling by free air convection, led indicator. It has a single phase input electrical phase . In addition, it has ac/dc-dc type power signal conversion . The product is available in din rail configuration. It carries 10 a output current. Applications Information involves industrial. The product ps-120, is a highly preferred choice for users. The product comes in 100mm depth. In addition, the height is 125mm. The typical product's weight is 0.79kg. Features a 12 v dc output voltage. Feature 120w of power rating. 264v ac is the maximum voltage of the bespoke product. The product has 88v ac of minimum input voltage.
