Number of Levels:
8
Fused:
No
Termination Type:
Push-in
Series:
PTRV
Colour:
Grey
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Terminal Block Current:
8A
Number of Positions:
2
Hazardous Area Certification:
No
Standards/Approvals:
UL, KEMA-KEUR, IECEE CB, IEC 60947-7-1, EAC, DNV GL, cULus, cUL, CSA
Voltage:
250 V
Cable CSA:
0.14 to 2.5 mm²
Maximum Wire Size AWG:
14 AWG
Product Type:
Non-Fuse DIN Rail Terminal
Maximum Operating Temperature:
105°C
Sub Type:
Marshalling
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Operating Temperature:
-
Type:
Marshalling Connector
Number of Positions:
32
Wire Gauge or Range - mm²:
0.14-2.5mm²
Height (Max):
3.740" (95.00mm)
title:
3270233
REACH Status:
REACH Unaffected
Housing Color:
Gray
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
8mm ~ 10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
8 A
Number of Levels:
8
Wire Gauge or Range - AWG:
14-26 AWG
Voltage - UL:
300 V
standardLeadTime:
4 Weeks
Terminal - Width:
8.3mm
Voltage - IEC:
250 V
Features:
-
Mounting Type:
DIN Rail
Series:
CLIPLINE PT
Length:
3.937" (100.00mm)
Packaging:
Bulk
Current - UL:
10 A
ECCN:
EAR99
