Number of Levels:
1
Fused:
No
Termination Type:
Plug-In
Series:
PT 2.5-TWIN/1P-PE
Colour:
Green, Yellow
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
26 AWG
Number of Positions:
1
Hazardous Area Certification:
No
Standards/Approvals:
ABS, Bureau Veritas, CSA, cUL, GOST, IEC 61984, LR, NK, RS, UL
Voltage:
6 kV
Cable CSA:
0.14 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
DIN Rail Terminal Block
Maximum Operating Temperature:
105°C
Sub Type:
Single-Level
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Plug Receptacles, Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Operating Temperature:
-
Type:
Plug Connection
Number of Positions:
3
Wire Gauge or Range - mm²:
0.14-4mm²
Height (Max):
1.732" (44.00mm)
title:
3209659
REACH Status:
REACH Unaffected
Housing Color:
Green, Yellow
Material Flammability Rating:
UL94 V-0
Manufacturer:
Phoenix Contact
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
2.382" (60.50mm)
Wire Gauge or Range - AWG:
12-26 AWG
standardLeadTime:
8 Weeks
Terminal - Width:
5.2mm
Number of Levels:
1; Grounded
Features:
-
Mounting Type:
DIN Rail
Series:
CLIPLINE PT
Packaging:
Bulk
ECCN:
EAR99
