Number of Levels:
1
Fused:
No
Termination Type:
Plug-In
Colour:
Blue
Minimum Operating Temperature:
-60°C
Minimum Wire Size AWG:
28 AWG
Terminal Block Current:
24A
Hazardous Area Certification:
No
Standards/Approvals:
VDE, UL, RS, LR, IECEE CB, IEC 61984, EAC, DNV GL, cULus, cUL, CSA, Bureau Veritas
Voltage:
500 V
Cable CSA:
0.08 to 4 mm²
Maximum Wire Size AWG:
12 AWG
Product Type:
Feed Through Terminal Block
Sub Type:
Plug-In
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Plug Receptacles, Push In, Spring
Material - Insulation:
Polyamide (PA), Nylon
Operating Temperature:
-
Type:
Plug Connection
Number of Positions:
2
Wire Gauge or Range - mm²:
0.08-4mm²
Height (Max):
1.732" (44.00mm)
REACH Status:
REACH Unaffected
Housing Color:
Blue
Material Flammability Rating:
UL94 V-0
Package:
Bulk
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
Not Applicable
Current - IEC:
24 A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-28 AWG
Voltage - UL:
600 V
standardLeadTime:
4 Weeks
Terminal - Width:
5.2mm
Voltage - IEC:
500 V
Features:
-
Mounting Type:
DIN Rail
Series:
CLIPLINE ST
Length:
1.988" (50.50mm)
Current - UL:
20 A
ECCN:
EAR99
