Series:
COMBICON Connectors
Colour:
Green
Material:
Copper Alloy, Polyamide
Accessory Type:
Flange Cover
Hazardous Area Certification:
No
Standards/Approvals:
IEC 60512-15-1:2008-05, EN 60695-10-2, EN 60695-2-12, EN 60695-2-13, IEC 60068-2-70:1995-12, IEC 60068-2-82, IEC 60112, IEC 60512-1-1:2002-02, IEC 60512-1-2:2002-02, IEC 60512-13-5:2006-02, IEC 60512-3-1:2002-02, IEC 60512-5-1:2002-02, IEC 60664-1:2007-04, IEC 60999-1:1999-11, ISO 6988:1985-02, JEDEC JESD 201, UL 94 V0
For Use With:
DIN Rail Terminal
Product Type:
Flange Cover
HTSUS:
8536.69.8000
RoHS Status:
ROHS3 Compliant
Termination Style:
Plug Receptacles, Screw
Material - Insulation:
Polyamide (PA), Nylon
Operating Temperature:
-
Type:
Plug Connection
Number of Positions:
1
Wire Gauge or Range - mm²:
0.2-4mm²
Height (Max):
-
title:
1850000
REACH Status:
REACH Affected
edacadModel:
1850000 Models
Housing Color:
Green
Material Flammability Rating:
UL94 V-0
edacadModelUrl:
/en/models/2528770
Manufacturer:
Phoenix Contact
Stripping Length:
10mm
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Current - IEC:
20 A
Number of Levels:
1
Wire Gauge or Range - AWG:
12-24 AWG
standardLeadTime:
11 Weeks
Terminal - Width:
7.6mm
Voltage - IEC:
630 V
Features:
-
Mounting Type:
DIN Rail
Series:
COMBICON PCVK
Length:
1.622" (41.20mm)
Packaging:
Bulk
ECCN:
EAR99
