Automotive Standard:
No
Maximum Drain Source Voltage Vds:
800V
Series:
MDmesh K6
Channel Type:
Type N
Typical Gate Charge Qg @ Vgs:
25.9nC
Package Type:
TO-220
Minimum Operating Temperature:
-55°C
Maximum Drain Source Resistance Rds:
0.6Ω
Standards/Approvals:
No
Maximum Continuous Drain Current Id:
10A
Product Type:
MOSFET
Maximum Operating Temperature:
150°C
Pin Count:
3
Mount Type:
Through Hole
FET Feature:
-
HTSUS:
8541.29.0095
Vgs(th) (Max) @ Id:
4V @ 100µA
Operating Temperature:
-55°C ~ 150°C (TJ)
Package / Case:
TO-220-3
Rds On (Max) @ Id, Vgs:
450mOhm @ 5A, 10V
Gate Charge (Qg) (Max) @ Vgs:
17.3 nC @ 10 V
RoHS Status:
ROHS3 Compliant
REACH Status:
REACH Unaffected
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
10V
Package:
Tube
Drain to Source Voltage (Vdss):
800 V
Vgs (Max):
±30V
Moisture Sensitivity Level (MSL):
3 (168 Hours)
Power Dissipation (Max):
100W (Tc)
Input Capacitance (Ciss) (Max) @ Vds:
700 pF @ 400 V
standardLeadTime:
16 Weeks
Mounting Type:
Through Hole
Series:
ECOPACK®
Supplier Device Package:
TO-220
Current - Continuous Drain (Id) @ 25°C:
10A (Tc)
Technology:
MOSFET (Metal Oxide)
Base Product Number:
STP80
ECCN:
EAR99
