Forward Voltage Vf:
1.6V
Width:
15.8 mm
Automotive Standard:
AEC-Q101
Typical Gate Charge Qg @ Vgs:
118nC
Package Type:
TO-247
Maximum Continuous Drain Current Id:
72A
Product Type:
MOSFET
Maximum Drain Source Resistance Rds:
39mΩ
Maximum Operating Temperature:
150°C
Maximum Drain Source Voltage Vds:
650V
Channel Type:
Type N
Length:
40.92mm
Standards/Approvals:
No
Pin Count:
3
Mount Type:
Surface
Maximum Power Dissipation Pd:
480W
Channel Mode:
Enhancement
Maximum Gate Source Voltage Vgs:
25 V
Series:
MDmesh DM6
Height:
5.1mm
Minimum Operating Temperature:
-55°C
FET Feature:
-
HTSUS:
8541.29.0095
RoHS Status:
ROHS3 Compliant
Operating Temperature:
-55°C ~ 150°C (TJ)
Package / Case:
TO-247-3
Rds On (Max) @ Id, Vgs:
39mOhm @ 36A, 10V
Gate Charge (Qg) (Max) @ Vgs:
118 nC @ 10 V
Vgs(th) (Max) @ Id:
4.75V @ 250µA
REACH Status:
REACH Unaffected
FET Type:
N-Channel
Drive Voltage (Max Rds On, Min Rds On):
10V
Drain to Source Voltage (Vdss):
650 V
Vgs (Max):
±25V
Qualification:
AEC-Q101
standardLeadTime:
16 Weeks
Input Capacitance (Ciss) (Max) @ Vds:
5900 pF @ 100 V
Mounting Type:
Through Hole
Grade:
Automotive
Series:
-
Supplier Device Package:
TO-247 Long Leads
Packaging:
Bulk
Current - Continuous Drain (Id) @ 25°C:
72A (Tc)
Power Dissipation (Max):
480W (Tc)
Technology:
MOSFET (Metal Oxide)
Base Product Number:
STWA68
ECCN:
EAR99
