Schneider Electric 1P+N 20 A RCBO, DIN Rail Mount, Trip Sensitivity 30mA Acti 9 iC60H

Enrgtech Part No: ET14150901
|
Manufacturer Part No:
A9D11820
|
Manufacturer: Schneider Electric

A9D11820 Schneider Electric 1P+N 20 A RCBO, DIN Rail Mount, Trip Sensitivity 30mA Acti 9 iC60H

Product Information

Current Rating:

20A

Application:

Distribution

Rated AC Voltage:

240V

Overall Length:

110mm

Overall Depth:

77.5mm

Breaking Capacity at Maximum Voltage Rating:

10 kA

Trip Sensitivity:

30mA

Tripping Characteristics:

Type C

Range:

Acti 9

Terminal Contact Type:

Screw

Special Features:

Short Circuit Protection

Earth Leakage Protection Type:

Checking for live stock

The A9D11820 RCBO from Schneider Electric is a space-saving, modular DIN-rail-mounted circuit protection device that combines overcurrent and residual-current protection in one. With a rated current of 20 A, residual-current sensitivity of 30 mA, and a C-curve tripping characteristic, it is designed for both personal protection against electric shock and reliable overload/short-circuit safeguarding in commercial and industrial distribution boards.

Crucial Features and Benefits of Choosing the Schneider Electric RCBO

1-pole plus neutral (1P + N) configuratio.
20 A rated current supports mid-range load circuits.
30 mA earth-leakage trip threshold for personnel safety.
Type C trip curve handles transient inrush currents (e.g., motor loads).
10 kA short-circuit breaking capacity, supporting robust fault protection.
Fits one module width on DIN-rail for compact panel layouts.
Combines MCB and RCD functionality, simplifying wiring and saving panel space.

Engineered for Safe and Efficient Distribution Boards

Part of the Acti9 iC60H range, the A9D11820 is built for modern electrical distribution panels where safety, space-efficiency and simplicity matter. Its combined protection simplifies installation by reducing the need for separate devices and wiring. Its design supports both retrofits and new builds, ensuring compatibility with existing Acti9 systems and compliance with IEC/EN 61009 standards for RCBOs.

Versatility in Applications

Protection of single-phase branch circuits (lighting, receptacles, HVAC) in commercial or industrial installations.
Usage in panelboards where space is limited and combined short-circuit/earth-leakage protection is preferred.
Circuits downstream of distribution boards serving loads with moderate inrush (e.g., motors, pumps).
Situations requiring personnel protection against electric shock and residual-current monitoring.

Datasheet(Technical Reference)

Instruction Sheet(Technical Reference)

Multi9 to Acti9 Reference Guide(Technical Reference)

Acti9 Ordering Guide(Technical Reference)

Product Environmental Profile(Technical Reference)
