EPCOS Surface Mount Pulse Transformer 1 : 0.22 :0.78 Turns Ratio, 4.1μH Prim. Inductance, 75mΩ Prim. Resistance

Enrgtech Part No: ET28424529
|
Manufacturer Part No:
B78308X0001
|
Manufacturer: EPCOS

B78308X0001 EPCOS Surface Mount Pulse Transformer 1 : 0.22 :0.78 Turns Ratio, 4.1μH Prim. Inductance, 75mΩ Prim. Resistance

Product Information

Primary DC Resistance:

75mΩ

Isolation Voltage:

3000V ac

Minimum Operating Temperature:

-40°C

Series:

E13 EMHV

Length:

15.8mm

Maximum Operating Frequency:

500kHz

Width:

12.90 mm

Depth:

11.4mm

Standards/Approvals:

IEC 60664-1, 61558-2-16

Turns Ratio:

1 : 0.22 :0.78

Primary Inductance:

4.1μH

Minimum Operating Frequency:

100kHz

Checking for live stock

This is Surface Mount Pulse Transformer 1 : 0.22 :0.78 Turns Ratio 4.1μH Prim. Inductance 75mΩ Prim. Resistance manufactured by EPCOS. The manufacturer part number is B78308X0001. Additionally, it has 75mω primary DC resistance . It has 3000v ac isolation voltage. Whereas, the minimum operating temperature of the product is -40°c. The product e13 emhv, is a highly preferred choice for users. Its accurate length is 15.8mm. It carries 500khz of maximum operating frequency. Furthermore, the product is 12.90 mm wide. The product comes in 11.4mm depth. It has 1 : 0.22 :0.78 turns ratio . Additionally, it has 4.1μh primary inductance . It has a minimum 100khz operating frequency . telecom transformer is a versatile product designed to provide user-defined applications. It has a maximum operating temperature of 150°c. It has a surface type mount .

Datasheet - B78308X0001(Technical Reference)
