Ratings:
UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
20
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
22 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
Not Applicable
Length:
Enter Number of Feet in Order Quantity
Spool Size:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
6 Weeks
Shield Coverage:
-
Features:
Biological Compatibility, Rip Cord
Jacket (Insulation) Diameter:
0.331" (8.41mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Packaging:
Digi-Spool®, Continuous Spool
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Base Product Number:
5010/20C
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5010
Fire Behaviour:
EN 60332-1, EN 60332-2
Screened/Unscreened:
Unscreened
American Wire Gauge:
22AWG
Standards/Approvals:
CE, CHINA RoHS, CSA, EU, IEC, RoHS, UL
Jacket Material:
Polyvinyl Chloride
Number of Cores:
20
Cable CSA:
0.34 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
