Hazardous Area Certification:
No
Jacket Colour:
Pastel Orange, Orange
Minimum Operating Temperature:
50°C
Conductor Material:
Copper
Series:
Servo
Fire Behaviour:
Flame Retardant acc. to IEC 60332-1-2 resp. EN 60332-1-2 UL: Vertical Flame test VW-1 acc. to UL 1581 § 1080 CSA: FT1 acc. to CSA C22.2 No. 2556
Screened/Unscreened:
Screened
Conductor Type:
Extra Fine
American Wire Gauge:
14AWG
Voltage:
1000 V
Jacket Material:
Thermoplastic Polyurethane, Polyurethane Compound Thermoplastic Polyurethane
Number of Cores:
4
Cable CSA:
2.5 mm²
Product Type:
Control Cable
Maximum Operating Temperature:
90°C
Standards/Approvals:
IEC 60811, IEC 60754-1, IEC 60332-1-2, IEC 60228, IEC 60092-360, EN ISO 4892-2-2013, EN 60754-1, EN 60332-1-2, EN 60228, EN 50620, EN 50618, EN 50575, EN 50525-2-21, EN 50396, EN 50395, EN 50363-10-2, EN 50334, EN 13501-6, CSA C22.2 No. 2556, CSA C22.2 No 210, CSA AWM C22.2 No.210, CSA 22.2 No. 210, UL AWM Style 20234, UL 758, UL 1581
Ratings:
UL Style 20234
HTSUS:
8544.49.3040
RoHS Status:
ROHS3 Compliant
Conductor Strand:
140/0.0059"; 56/0.0059"
Operating Temperature:
-
Usage:
Industrial
title:
0027970
Number of Conductors:
8 (2 Twisted Pairs + 4)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Polyurethane (PU)
Wire Gauge:
14 AWG, 18 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
-
Moisture Sensitivity Level (MSL):
Not Applicable
Length:
Enter Number of Feet in Order Quantity
Spool Size:
300.0' (91.4m)
Conductor Insulation:
Polypropylene (PP)
standardLeadTime:
11 Weeks
Shield Coverage:
85%
Features:
Abrasion Resistant, Flame Retardant, Oil Resistant
Jacket (Insulation) Diameter:
0.575" (14.61mm)
Conductor Material:
Copper, Bare
Series:
ÖLFLEX®
Cable Type:
Multi-Conductor
Packaging:
Digi-Spool®, Continuous Spool
Voltage:
1000 V
Shield Material:
Copper, Tinned
ECCN:
EAR99
Jacket Color:
Orange
