Ratings:
-
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
Solid
Operating Temperature:
-40°C ~ 80°C
Usage:
Industrial, Network
title:
2170474
Number of Conductors:
8 (4 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
22 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
-
Moisture Sensitivity Level (MSL):
Not Applicable
Length:
25.00' (7.62m)
Conductor Insulation:
Polyethylene (PE)
Shield Coverage:
100%
Features:
Abrasion Resistant, Oil Resistant
Jacket (Insulation) Diameter:
0.343" (8.71mm)
Conductor Material:
Copper, Bare
Series:
ETHERLINE®
Cable Type:
Multi-Pair, Cat7
Packaging:
Bulk
Voltage:
100 V
Shield Material:
Copper
ECCN:
EAR99
Jacket Color:
Green
Product Type:
Cat7 Cable
Outside Diameter:
8.70 mm
Conductor Material:
Bare Copper
Series:
ETHERLINE
Shield Type:
Shielded
Fire Behaviour:
Flame Retardant, No Flame Propagation, Oil Resistant
Core Strands:
22
Cable Length:
100m
Screened/Unscreened:
Screened
Minimum Operating Temperature:
30°C
Jacket Colour:
Green
Standards/Approvals:
EN 50173, EN 50288-4-1, EN 60332-1-2, EN 60332-3-25, EU-Directive 2011/65/EU (RoHS), IEC 60332-1-2, IEC 60332-3-25, IEC 61156-5, ISO/IEC 11801, LV-Directive 2014/35/EU
Voltage:
100 V
Jacket Material:
Polyvinyl Chloride
Number of Cores:
8
LAN Category:
Cat7
Maximum Operating Temperature:
80°C
Sub Type:
Installation Cable
Conductor Type:
Solid
