Hazardous Area Certification:
RoHS
Jacket Colour:
Grey
Outside Diameter:
0.231 in
Conductor Material:
Tin Copper Wire
Series:
Xtra-Guard 1 Performance Cable
Minimum Operating Temperature:
-35°C
Fire Behaviour:
EN 60332-2, EN 60332-1
Core Strands:
22
Armoured:
No
Screened/Unscreened:
Unscreened
Conductor Type:
Stranded
American Wire Gauge:
22
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
6
Cable CSA:
0.46 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
Standards/Approvals:
Directive 2015/863/EU, Directive 2011/65/EU
Ratings:
ISO 10993, UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
7/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
6
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
4 Weeks
Shield Coverage:
-
Features:
Biological Compatibility, Rip Cord
Jacket (Insulation) Diameter:
0.219" (5.56mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Base Product Number:
5006C
Jacket Color:
Slate
