Ratings:
ISO 10993, UL Style 2661
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
10/34
Operating Temperature:
-
Usage:
-
Number of Conductors:
16 (8 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
24 AWG
Shield Type:
Foil, Braid
Jacket (Insulation) Thickness:
0.0400" (1.016mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
19 Weeks
Shield Coverage:
100%, 85%
Features:
Biological Compatibility, Drain Wire
Jacket (Insulation) Diameter:
0.385" (9.78mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® Flex
Cable Type:
Multi-Pair
Packaging:
Spool
Voltage:
300 V
Shield Material:
Aluminum; Copper, Tinned
ECCN:
EAR99
Base Product Number:
86608CY
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Outside Diameter:
0.385 in
Conductor Material:
Tin Copper Wire
Series:
8660
Minimum Operating Temperature:
-10°C
Core Strands:
8
Armoured:
No
Screened/Unscreened:
Screened
American Wire Gauge:
24AWG
Standards/Approvals:
CE: EU Directive 2011/65/EU(RoHS2), CSA International, EU Directive 2015/863/EU (RoHS3), REACH Regulation (EC 1907/2006), UL
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
8
Cable CSA:
0.25 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
