Ratings:
ISO 10993, UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/34
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
8 (4 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
26 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
5 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.227" (5.77mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Packaging:
Spool
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5692
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5692
Fire Behaviour:
EN, EN 60332-1
Screened/Unscreened:
Screened
American Wire Gauge:
26AWG
Standards/Approvals:
EU Directive 2011/65/EU(RoHS2), EU Directive 2015/863/EU (RoHS3), EU Low Voltage Directive 2014/35/EU
Jacket Material:
Polyvinyl Chloride
Number of Cores:
4
Cable CSA:
0.14 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
