Ratings:
ISO 10993
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
16/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
12 (6 Pair Twisted)
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
18 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
6 Weeks
Shield Coverage:
-
Features:
Biological Compatibility, Rip Cord
Jacket (Insulation) Diameter:
0.460" (11.68mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Packaging:
Spool
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Base Product Number:
5036C
Jacket Color:
Slate
Hazardous Area Certification:
EU
Jacket Colour:
Grey
Minimum Operating Temperature:
-30°C
Conductor Material:
Tin Copper Wire
Series:
5036C
Fire Behaviour:
EN 60332-1, EN 60332-2
Core Strands:
6
Screened/Unscreened:
Unscreened
American Wire Gauge:
18AWG
Standards/Approvals:
UL AWM/STYLE 2517 105C / 300 VRMS SUN RES, RoHS, UL AWM/STYLE 1569 105C / 300 VRMS, UL AWM/STYLE 2464 80C / 300 VRMS CM 105C VW-1, China RoHS 2 per GB/T 26572-2011, China RoHS Marking for Control of Pollution by Electronic Information Products Standard SJ/T 11364-2014, CSA International C(UL) TYPE CMG 105C FT4, IEC EN 60332-1, IEC EN 60332-2
Jacket Material:
Polyvinyl Chloride
Cable CSA:
0.75 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
