Ratings:
ISO 10993, UL Style 2501
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/28
Operating Temperature:
-30°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
9
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
20 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0630" (1.600mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
5 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.507" (12.88mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Packaging:
Spool
Voltage:
600 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5420/9
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-30°C
Conductor Material:
Tin Copper Wire
Series:
5420
Fire Behaviour:
EN 60332-1, EN
Screened/Unscreened:
Screened
American Wire Gauge:
20AWG
Standards/Approvals:
UL, RoHS, IEC, CSA, CHINA RoHS, CE
Jacket Material:
Polyvinyl Chloride
Number of Cores:
9
Cable CSA:
0.5 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
