Ratings:
ISO 10993, UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
19/0.0117"
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
6
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
16 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
500.0' (152.4m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
29 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.347" (8.81mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5366C
Jacket Color:
Slate
Hazardous Area Certification:
EU
Jacket Colour:
Grey
Minimum Operating Temperature:
-30°C
Conductor Material:
Tin Copper Wire
Series:
5366
Fire Behaviour:
EN 60332-1, EN 60332-2
Screened/Unscreened:
Screened
American Wire Gauge:
16AWG
Standards/Approvals:
UL AWM/STYLE 1569 105C / 300 VRMS, Overall AWM/STYLE 2517 105C / 300 VRMS SUN RES AWM/STYLE 2464 80C / 300 VRMS CM 105C VW-1, CSA International C(UL) TYPE CMG 105C FT4
Jacket Material:
Polyvinyl Chloride
Number of Cores:
6
Cable CSA:
1.5 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
500ft
