Hazardous Area Certification:
EU
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5199
Fire Behaviour:
EN
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
AWM/STYLE 2517 105C / 300 VRMS SUN RES AWM/STYLE 2464 80C / 300 VRMS CM 105C VW-1, CE: EU Low Voltage 2014/35/EU, CSA International CMG 105C FT4, IEC EN 60332-1 Flame Behavior EN 60332-2 Flame Behavior, UL AWM/STYLE 10002 105C / 300 VRMS, Oil Resistant
Jacket Material:
Polyvinyl Chloride
Number of Cores:
10
Cable CSA:
0.34 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
500ft
Ratings:
ISO 10993
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
7/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
10
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
500.0' (152.4m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
5 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.272" (6.91mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5199/10C
Jacket Color:
Slate
