Hazardous Area Certification:
No
Jacket Colour:
Grey
Outside Diameter:
0.324 in
Conductor Material:
Tin Copper Wire
Series:
5386
Minimum Operating Temperature:
30°C
Fire Behaviour:
EN 60332-2, EN 60332-1
Core Strands:
18
Screened/Unscreened:
Screened
Conductor Type:
Stranded
American Wire Gauge:
18AWG
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
6
Cable CSA:
0.75 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
Standards/Approvals:
RoHS, UL, REACH, IEC EN 60332-1, EN 60332-2, CSA, CE
Ratings:
ISO 10993, UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
16/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
6
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
18 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
4 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.311" (7.90mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5386C
Jacket Color:
Slate
