Ratings:
ISO 10993, UL Style 2464
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
7/28
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
30 (15 Pair Twisted)
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0320" (0.813mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
500.0' (152.4m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
10 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.451" (11.46mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5489/15C
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5489
Fire Behaviour:
EN 60332-1, EN 60332-2
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
CE: EU Directive 2011/65/EU(RoHS2), CE: EU Low Voltage Directive 2014/35/EU, EU Directive 2015/863/EU, IEC, REACH, RoHS
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
15
Cable CSA:
0.34 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
500ft
