Manufacturer Standard Lead Time:
3 Weeks
Ratings:
ISO 10993, UL Style 2661
Operating Temperature:
-10°C ~ 105°C
Number of Conductors:
12 (6 Pair Twisted)
Conductor Strand:
7/36
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Standard Package:
1
Manufacturer:
Alpha Wire
Jacket (Insulation) Thickness:
0.040" (1.02mm)
Wire Gauge:
28 AWG
Shield Type:
Foil, Braid
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
500.0' (152.4m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
Shield Coverage:
100%, 85%
Features:
Biological Compatibility, Drain Wire
Jacket (Insulation) Diameter:
0.293" (7.44mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® Flex
Cable Type:
Multi-Pair
Voltage:
300V
Shield Material:
Aluminum; Copper, Tinned
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Outside Diameter:
0.293 in
Conductor Material:
Tin Copper Wire
Series:
8640
Minimum Operating Temperature:
-10°C
Core Strands:
6
Armoured:
No
Screened/Unscreened:
Screened
American Wire Gauge:
28AWG
Standards/Approvals:
REACH Regulation (EC 1907/2006), CSA International, EU Directive 2015/863/EU (RoHS3), UL, CE: EU Directive 2011/65/EU(RoHS2)
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
6
Cable CSA:
0.08 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
500ft
