Manufacturer Standard Lead Time:
3 Weeks
Ratings:
ISO 10993, UL Style 2464
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
12 (6 Pair Twisted)
Conductor Strand:
7/36
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Standard Package:
1
Manufacturer:
Alpha Wire
Jacket (Insulation) Thickness:
0.032" (0.81mm)
Wire Gauge:
28 AWG
Shield Type:
Foil, Braid
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
Shield Coverage:
100%, 70%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.270" (6.86mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Voltage:
300V
Shield Material:
Suprashield®; Copper, Tinned
Jacket Color:
Slate
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Copper
Series:
5947
Hazardous Area Certification:
No
Conductor Type:
DCR
American Wire Gauge:
28AWG
Voltage:
300 V
Jacket Material:
Polyvinyl Chloride
Number of Cores:
6
Cable CSA:
0.08 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
Standards/Approvals:
ANSI/ESD S20.20:2021, RoHS
