Manufacturer Standard Lead Time:
3 Weeks
Ratings:
ISO 10993
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
22 (11 Pair Twisted)
Conductor Strand:
7/32
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Standard Package:
1
Manufacturer:
Alpha Wire
Jacket (Insulation) Thickness:
0.032" (0.81mm)
Wire Gauge:
24 AWG
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
Features:
Biological Compatibility, Rip Cord
Jacket (Insulation) Diameter:
0.357" (9.06mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Pair
Voltage:
300V
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5269
Fire Behaviour:
EN 60332-1, EN 60332-2
Core Strands:
7
Screened/Unscreened:
Unscreened
American Wire Gauge:
24AWG
Standards/Approvals:
California Proposition 65, EU 2011/65/EU (RoHS2), EU 2015/863/EU (RoHS3), REACH (EC 1907/2006)
Jacket Material:
Polyvinyl Chloride
Number of Cores:
11
Cable CSA:
0.25 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
