Ratings:
ISO 10993
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Conductor Strand:
7/30
Operating Temperature:
-35°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
12
REACH Status:
REACH Unaffected
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Wire Gauge:
22 AWG
Shield Type:
-
Jacket (Insulation) Thickness:
0.0630" (1.600mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
6 Weeks
Shield Coverage:
-
Features:
Biological Compatibility, Rip Cord
Jacket (Insulation) Diameter:
0.338" (8.59mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Packaging:
Spool
Voltage:
300 V
Shield Material:
-
ECCN:
EAR99
Base Product Number:
5212C
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5212
Fire Behaviour:
EN 60332-1, EN 60332-2
Screened/Unscreened:
Unscreened
American Wire Gauge:
22AWG
Standards/Approvals:
UL AWM/STYLE 21895 105C / 300 VRMS SUN RES 60C OIL AWM/STYLE 2343 80C CM 105C VW-1, CE: EU Low Voltage 2014/35/EU, CSA International CMG 105C FT4, EN 60332-2 Flame Behavior, IEC EN 60332-1 Flame Behavior
Jacket Material:
Polyvinyl Chloride
Number of Cores:
12
Cable CSA:
0.34 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
