Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-35°C
Conductor Material:
Tin Copper Wire
Series:
5581
Fire Behaviour:
EN 60332-2, EN 60332-1
Screened/Unscreened:
Screened
American Wire Gauge:
22AWG
Standards/Approvals:
California Proposition 65, CSA, EU Directive 2011/65/EU(RoHS2), EU Directive 2015/863/EU (RoHS3), EU Low Voltage Directive 2014/35/EU, IEC, REACH Regulation (EC 1907/2006), UL
Jacket Material:
Polyvinyl Chloride
Number of Cores:
7
Cable CSA:
0.34 mm²
Product Type:
Cable
Maximum Operating Temperature:
105°C
Cable Length:
1000ft
Ratings:
UL Style 21895
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
7/28
Operating Temperature:
-30°C ~ 105°C
Usage:
-
Number of Conductors:
7
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
22 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0630" (1.600mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
1000.0' (304.8m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
4 Weeks
Shield Coverage:
100%
Features:
Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.285" (7.24mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
300 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5581C
Jacket Color:
Slate
