Ratings:
ISO 10993, UL Style 2501
HTSUS:
8544.49.3080
RoHS Status:
ROHS3 Compliant
Jacket (Insulation) Material:
Poly-Vinyl Chloride (PVC)
Conductor Strand:
16/30
Operating Temperature:
-30°C ~ 105°C
Usage:
Communication, Control
Number of Conductors:
2
REACH Status:
REACH Unaffected
Package:
Spool
Wire Gauge:
18 AWG
Shield Type:
Foil
Jacket (Insulation) Thickness:
0.0630" (1.600mm)
Moisture Sensitivity Level (MSL):
1 (Unlimited)
Length:
100.0' (30.5m)
Conductor Insulation:
Poly-Vinyl Chloride (PVC)
standardLeadTime:
7 Weeks
Shield Coverage:
100%
Features:
Biological Compatibility, Drain Wire, Rip Cord
Jacket (Insulation) Diameter:
0.356" (9.04mm)
Conductor Material:
Copper, Tinned
Series:
Xtra-Guard® 1
Cable Type:
Multi-Conductor
Voltage:
600 V
Shield Material:
Aluminum
ECCN:
EAR99
Base Product Number:
5430/2
Jacket Color:
Slate
Hazardous Area Certification:
No
Jacket Colour:
Grey
Minimum Operating Temperature:
-30°C
Conductor Material:
Tin Copper Wire
Series:
5430
Fire Behaviour:
EN 60332-1, EN 60332-2
Screened/Unscreened:
Screened
American Wire Gauge:
18AWG
Standards/Approvals:
CE: EU Directive 2011/65/EU(RoHS2), CE: EU Low Voltage Directive 2014/35/EU, EU Directive 2015/863/EU, IEC, REACH, RoHS
Voltage:
300 Vrms
Jacket Material:
Polyvinyl Chloride
Number of Cores:
2
Cable CSA:
0.75 mm²
Product Type:
Multicore Cable
Maximum Operating Temperature:
105°C
Cable Length:
100ft
